規格

Current Rating : 1A AC,DC

Voltage Rating : 125V AC,DC

Temperature Range : -25 deg C ~+85 deg C

Contact Resistance : 20m Omega Max.

Insulation Resistance : 100M Omega Min.

Withstanding Voltage : 500V AC/minute

PIN:2~20PIN
