規格

Current Rating : 1A AC,DC

Voltage Rating: 100V AC

Temperature Range : -25 deg C ~+85 deg C

Contact Resistance: 30m Omega Max.

Insulation Resistance: 500M Omega Min.

Withstanding Voltage : 500V AC/minute

PIN:8~30PIN
