規格

Voltage rating: 250V AC/DC.

Current rating: 1A AC/DC.

Withstanding voltage: 250 VAC for 1 min.

Insulation resistance: 100 MΩ Min.

Contact resistance: 20 mΩ Max..

Temperature range: -40℃~85℃

Contact: Brass with Tin plated.

PIN:2~15PIN
