規格

Current Rating: 1A AC, DC.

Voltage Rating: 125V AC, DC.

Temperature Range: -25 deg C ~ +85 deg C.

Contact Resistance: 20m Omega Max..

Insulation Resistance: 100M Omega Min.

Withstanding Voltage: 500V AC/minute

PIN:2~30PIN
