規格

Current Rating: 3A AC, DC.

Voltage Rating: 250V AC, DC.

Temperature Range: -25 deg C ~ +85 deg C.

Contact Resistance: 10m Omega Max.

Insulation Resistance: 1,000M Omega Min.

Withstanding Voltage: 800V AC/minute

PIN:4~40PIN
